Wireless Microphone System

 Solution Description



DSPPA new wireless conference room microphone system provides a new energy-saving mode, with automatic EQ control, tone correction and IR frequency synchronization functions. It uses the unique audio compressor design to effectively eliminate howling and completely eliminate interference signals to ensure that the system has a strong anti-interference function.

Therefore, with high flexibility and reliability, our UHF wireless conference microphone system is easy to operate and has compact structure, and the wireless microphone for conference room can be perfectly integrated into existing conference rooms without additional wiring, which is an ideal choice for mobile conference systems.



Solution Design



Usually, in a small closed indoor environment, it is not always the best to install more speakers. Generally, speakers are placed in pairs, mainly for symmetry, and reflecting the left and right channels for uniform sound field and appropriate loudness.

1. Audio source devices

Adopt a wireless microphone system (D5814/D5817) for conferences and speeches.

2. Audio processors

Adopt a mixer (MG12) to modify the audio source, and a feedback suppressor D6573, a digital processor D6575 and other devices to enhance on-site sound effects.

3. Speakers and amplifiers

Adopt two 250W full-range wall mount speakers (D6564), which uses a 10" woofer and a 1" tweeter to ensure sound effects, and a dual-channel 2*400 professional amplifier (MX2500II) to amplifier the power.



System Features



1. The human voice can be better reflected in meetings and academic reports, with clear sound and uniform sound field.

2. The infrared conference microphone has high flexibility and reliability, and uses a new type of anti-howling unidirectional high-sensitivity pickup microphone for perfect sound.

3. It can realize sound signal transmission with high fidelity, high SNR, strong anti-interference, no sound delay, etc.

4. The audio processors can make the speakers provide stable, clear and professional conference sound reinforcement effects.

5. The system can be used to various meeting forms such as conferences, speech reports, etc.

6. Easy to operate, the user can speak when he turns on the microphone switch, with compact structure, simple wiring, economical and affordable.



Series Products



The new generation of UHF conference room speaker and microphone system is composed of microphones and receivers. Among them, the microphones include handheld, clip, headset, and desktop microphones, while the receivers have two channels, four channels and eight channels. It can realize frequency synchronization between any receiver and any microphone in the system, providing customers with a variety of combination options.



7. Main Devices

D5815

2-channel UHF Wireless Microphone Receiver



Receiver Feature：

● PLL 2/4/8-channel phase-locked loop design.

● UHF 200-channel PLL digital lock automatic communication function.

● IR frequency pairing.

● Display function (display frequency, channel, squelch, level, etc.).

● With volume control for each channel.

● AF output (using “XLR” type socket for independent output and mixed output).



There are many pa system manufacturers, but we are one of the best choices for you.



DSPPA Ultra Directional Speaker

 DSPPA – ultra directional speaker

Enables you to focus a beam of sound to a specific point in the environment and to address the public with precise acoustic content at precise locations.

Features:

The LA1525SD speaker offers highly directional distribution of sound, which is reproduced clearly – without distortion – even at high volumes. The sound is of high-quality, with low noise and great frequency response, which includes authentic reproduction of bass notes and frequencies as low as 180 Hz. The speaker itself is easy to use – you only need to connect the mixer amplifier



Applications:

* Retail

* Museum and gallery installatio

* Fairs and trade show

* Automotive applicatio

* Bars, restaurants etc.



Audio Footprint Comparison

DSPPA's directional speaker audio travels in a focused direction along a narrow beam, unlike typical point source loudspeakers that emit sound waves in all direction.



For more information about pa system in chinese, please feel free to contact us!



Large Mosque + Invisible Speaker & Horn Speaker

 1. Solution Description

The large mosque, an important religious holy site,is mainly built for worship and prayer activities, withtwo floors, and a minaret ofover 20 meters in height. In the local area, major religious events and religious festivals are usually held here.Itis spacious, with many prayer rooms distributed on different floors.Therefore, we design a high-quality sound reinforcement system for it, which is used in daily lectures, missions and other activities.

In this system, the invisible wall-mounted speakers specially designed for high-end buildingscan match the surrounding environment,while notdestroying any decoration style of the scene, giving people a high-quality listening experience, with directivityangleof 180°,allowing uniformsoundinevery corner of the hall. The high-power outdoor waterproof horn speaker makes the sacred sound spread wider and farther, and more shocking. In addition, we usedifferentmicrophones to facilitate speech needs in different situations and different bodymanners.

1. Application Scene



1. Attainable Functions

§. Equipped with wired handheld microphone D6561, wireless handheld microphone D6650,andlavalier microphone D6653, to meet the master’s presidingandspeech, as well as the worship of the congregation.

§.With timer MP1715T, toprovide audio sources, and play theprayersregularly every day.

§. The player MAG2107C has CD, USB,FMand Bluetooth functions,to provide a variety of audio source media for the system.

§. Professional multi-channel mixerandprofessional digital audio pre-processor can better improve the sound quality, and shape the desired sound effects according to the program or site characteristics. Combined with the invisible speaker DSP40I, installedin the wall, you can realize the wonderfuleffect, that is,only the sound can be heard,while the speaker can not be found,truly invisible, and withoutspacelimitation, making music everywhere, providing a comfortable and elegant listening environment, andhigh-quality music experience.



1. Main Devices

DSP40I (40W Invisible Speaker）





This masjid speaker system can be radiated in all directions;

The sound pressure level fall off is more gradual off axis and in a bounded space;

Radiate sound energy is random, diffused and highly dispersed;

Visual appearance can be matched to the surrounding decoration.



InPUT  VOLTAGE：70V/100V

RATED POWER：40W

FREQUENCY  RESPONSE：100Hz-20kHz

CONVERSION EFFICIENCY：16％

SENSITIVITY：87dB

MAX SOUND LEVEL：103dB

Directivity Angle：180°

Dimension：300mm×400mm×52mm

Weight：1.7Kg

DSP3008A (150WWaterproof Stadium HornLoudspeaker)





Out door design，suited for out-door and in-door use；

Weight 25kg，with mounting holes for three-point installation;

Dispersion  70º×50º ；

Wide frequency，sound clear and sonorousness。



INPUT  VOLTAGE：70V/100V

RATED POWER：150W

FREQUENCY  RESPONSE：120Hz-18kHz

CONVERSION EFFICIENCY：16％

SENSITIVITY：104dB

MAX SOUND LEVEL：126dB

DISPERSION(H*V)：70º×50º  （500Hz-4kHz,-10dB）



MP1715T (PA System ProgramTiming Player)





4.3” TFT colorful liquid crystal touch screen to display all the states of the equipment and achieve the operation and control by the touch screen.

Display of captions in Chinese/English for selection.

Playing of MP3 music program from U-disc and SD card.

Playing of MP3 music program from SD card on a timing basis.

Editing of 8 timing programs which are circulated on a weekly basis; editing of not more than 100 timing points in a daily program; with timing point information power failure memory function.

Editing of timing point on the computer, which is copied through SD card to this equipment for implementation, or copying of the timing point on this equipment through SD card to the computer for storage and backup.

A route of AC 220V 2000W power output socket with the function of timing on-off by timing control of the timing point.

The function of turn on the power of the equipment within 1-60 seconds (time settable) before the timing point is coming.

A route of short circuit signal output interface interlinked with timing power output, and a route of audio signal output interface (Output of four sockets in parallel).

Connected to earphone to monitor playing state.

Output of LED level indication.



D6575 (Digital Audio Processor)

The main parameters of the channel can be controlled through S terminal connection;

Music signal provides optical fiber and coaxial input, and each output provides fiber output mode;

96KHz sampling frequency, 32-bit DSP processor, 24-bit A/D and D/A conversion;

The output channel also controls the ratio of effects to the channel, the microphone volume, the music volume, and the effect volume;

The effect with three-segment parametric equalization and a pair of high and low pass filter, echo and effect of the specific parameters can be adjusted;

Provide USB interface, WiFi or cable network interface can connect the computer; provide remote control and infrared control;

Directly use the function keys of the panel and the drawing wheel to set up or connect the computer through the PC control software to control;

Using Chinese character LCD screen and 6-segment LED display input/output accurate digital level meter, mute sound and edit state;

The microphone volume, the effect volume, the music volume and the total volume are respectively controlled by the different knobs of the direct rotating panel;

The single machine provides 20 sets of equipment data storage and 10 sets of effect data storage, through the PC software can copy between the equipment;

Each input and output have delay and phase control and mute settings, input delay can reach up to 30ms, output delay up to 60ms;

Through the panel "system" button to set the password lock panel operation of some or all of the features to prevent the operation of miscellaneous personnel undermine the working condition of the machine;

2-channel optional audio signal input, each audio signal input sensitivity is optional, providing 3 sets of 5 microphone input, standard 6-channel output.



MG16 (16 Channel mixer)



Ø Up to 10 microphones / 16 line inputs (8 mono + 4 stereo)

Ø 4 group bus + 1 stereo bus

Ø 4 AUX (including FX)

Ø "D-PRE" speaker, with a reverse transistor circuit.

Ø Single knob compressor

Ø PAD switch on mono input channel

Ø + 48V phantom power

Ø XLR balanced output

Ø The world's internal internal power supply

Ø Includes cabinet installation kit

Ø Metal body



For more information about mosque speaker and pa system in chinese, please feel free to contact us!



Multimedia Amplifier for Mosques-MA2250U

 DSPPA microphone system for mosque



Amplifier Sound System Introduction



The Mosque can accommodate very large number of prayers and usually everyone prefers to pray in the mosque. The Holy Qaran which is recited at the mosque is heard by all the people who are living in the same community. Hence, it’s important to have a better mosque sound system that can produce a pleasant audio quality.

DSPPA MA2250U is specially designed for mosques - the perfect choice for every small and medium-sized mosque sound system. It has two built-in 250W amplifiers and a mixer with digital sound processor, as well as a built-in effector. Besides, it has multi-channel MIC inputs with reverberation effect, and it can be externally connected to Azan audio, with MP3/Bluetooth and other audio sources optional. The amplifier has two channels of constant-voltage and constant-resistance outputs, with independent volume adjustment for each channel. Therefore, it is an integrated system that can best meet your various requirements.



Amplifier Features



Compact All-in-one Device Digital Mixer Amplifier

MA2250U is a 2-channel multimedia mixer amplifier for mosques, with RMS power of 2*250W. Support separate control of Echo/Bass/Treble/Volume for 2-channel ouputs,  with built-in 3 MIC, 1 AUX and USB/Bluetooth. MA2250U is the perfect choice for your mosque.



Better than other masjid speaker system:

Generally, the masjid sound system consists of sound amplifiers, horn speakers, ceiling speakers, sound mixers and microphones. Since the quality of these equipment varies from brand to brand, the price of the sound system is based on the quality, and the complicated sound system setup and different microphones will cause more sound quality problems, DSPPA has designed an integrated power amplifier MA2250U specially for small and medium-sized houses of worship.



The voice of Imam should be sent to every worshipper in the mosque, and must be clearly heard in the farthest corners. Therefore, microphones and speakers should be carefully selected and installed according to the architectural and acoustic characteristics of the mosque.

However, most of mosques are rarely considered from the acoustic aspect, so the echo, longer reverberations of sound and feedback will affect the intelligibility of Azan and Khutba.



2 Channels of Speaker Output & ECHO Function
